Fanvil X7A Android IP Phone with Camera

The Fanvil X7A Android IP Phone is an advanced communication solution designed to revolutionize your business interactions. This device blends the functionality of Android OS with the reliability of a premium IP phone, making it a perfect fit for the dynamic Nigerian market.

Key Features

1. High-Definition Voice Clarity: The Fanvil X7A ensures every conversation is crystal clear, thanks to its superior HD audio capabilities.
2. Integrated Camera for Video Conferencing: Equipped with a built-in camera, the X7A transforms into a powerful tool for video calls.
3. Android Operating System: Access a plethora of apps to enhance productivity, schedule meetings, and manage your tasks efficiently, all from your phone.
4. Large Touchscreen Display: Navigate with ease on the X7A’s expansive touchscreen display.
5. Customizable Function Keys: Tailor your phone to your business needs. With programmable keys, you can set quick dials, access essential features, and streamline your workflow.
6. Connectivity Options: Featuring Wi-Fi and Bluetooth support, the X7A offers flexible connectivity.

Generic

• 20 SIP Lines
• HD Voice
• Support receiving video call
• PoE Enabled
• 7-inch (1024×600) colour touch screen
• Handset / Hands-free / Headset mode
• Intelligent DSS Keys(Virtual buttons)
• Optional External Power Supply

Operation System

• Android 9.0 OS with higher security and better compatibility
• Built-in Applications: Files, Calendar, Gallery, Browser, Email, Calculator, Notepad, Sound Recorder, Clock, Video, Music
• Support 3rd Party Applications
• Secondary Development of API

Phone Features

• Local Phonebook (2000 entries)
• Remote Phonebook (XML/LDAP, 2000 entries)
• Intelligent Search for Contacts and Call Log
• Call logs (In/out/missed, 1000 entries)
• Black/White List Call Filter
• Screen saver
• Voice Message Waiting Indication (VMWI)
• Programmable DSS/Soft keys
• Network Time Synchronisation
• Built-in Bluetooth 4.2: Support Bluetooth headset/ Bluetooth of Mobile Device
• Built-in WiFi:
  – 2.4GHz, 802.11 b/g/n
  – 5GHz, 802.11 a/n/ac
• Support Recording
• Action URL / Active URI
• UaCSTA
• Audio/Video Recording
• SIP Hotspot
• Group Broadcasting
• Action Plan
• Group listening

Call Features

• Call out / Answer / Reject
• Mute / Unmute (Microphone)
• Call Hold / Resume
• Call Waiting
• Intercom
• Caller ID Display
• Speed Dial
• Anonymous Call (Hide Caller ID)
• Call Forwarding (Always/Busy/No Answer)
• Call Transfer (Attended/Unattended)
• Call Parking/Pick-up (Depending on server)
• Redial
• Do-Not-Disturb
• Auto-Answering
• Voice Message (On server)
• 5-way Audio Conference
• Hot Line
• Hot desking
• BLF

Video

• Video decoding: H.264
• Video call resolution: CIF/VGA/4CIF/720P
• Image format: JPEG/PNG/BMP
• Video format: MP4
• Bandwidth selection: 64kbps~4Mbps
• Frame rate selection: 5~30fps
• Video from a remote site can be displayed in full screen
• 3-way Video Call with External Camera Fanvil CM60
• Optional Fanvil CM60 USB Camera:
  – 2 Mega Pixel
  – Plug and Play
  – Flexible Placement and Angle Adjustment
• Video Preview

Audio

• HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
• HAC handset
• Wideband ADC/DAC 16KHz Sampling
• Narrowband Codec: G.711a/u, G.729AB, iLBC
• Wideband Codec: G.722, Opus
• Full-duplex Acoustic Echo Canceller (AEC)
• Noise Reduction (NR)
• Packet Loss Concealment (PLC)
• Dynamic Adaptive Jitter Buffer
• DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO

Network

• Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
• IP Mode: IPv4
• IP Configuration: Static / DHCP
• Network Access Control: 802.1x
• VPN: OpenVPN (Requires third-party app support)
• VLAN
• LLDP
• CDP
• QoS

Protocols

• SIP2.0 over UDP/TCP/TLS
• RTP/RTCP/SRTP
• STUN
• DHCP
• CDP
• LLDP
• PPPoE
• 802.1x
• OpenVPN (Requires third-party app support)
• SNTP
• FTP/TFTP
• HTTP/HTTPS
• TR-069

Deployment & Management

• Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069
• Web Management Portal
• Supports the third-party communication APP
• Supports Web, Telnet
• Supports encrypted configuration files download with AES
• Supports Web upgrade
• Supports factory reset data
