Grandstream GWN7630 Indoor Dual-Band WiFi Access Point
₦82,130.00
- 200 concurrent Wi-Fi client devices
- 175-meter coverage range
- 4 dual-band internal antennas
- 2.33 Gbps wireless throughput
- Description
- Reviews (0)
- Specifications
The Grandstream GWN7630 is a high-performance Wi-Fi Access Point designed to provide extended coverage and maximum network throughput. It is a highly effective solution for medium-to-large sized businesses seeking a reliable, superior quality wireless networking system. This Wi-Fi access point operates on a dual-band frequency of 2.4 GHz and 5 GHz, delivering a combined wireless data rate of up to 2.33 Gbps. It facilitates broad coverage with a range of up to 175 meters and supports up to 200 concurrent users, making it an ideal solution for dense user environments such as offices, hotels, universities and commercial establishments.
The GWN7630 features advanced antenna technology with multiple spatial streams, beamforming, and MU-MIMO capabilities to enhance network performance and ensure stable connectivity even in challenging conditions. Additionally, the product incorporates powerful QoS protocols that prioritize bandwidth for critical applications ensuring seamless, uninterrupted communication.
Embedded with cutting-edge security features such as WPA3 encryption and dual Gigabit network ports with PoE/PoE+ support, the GWN7630 guarantees secure and efficient power delivery and data transmission. The device is easy to manage via the GWN.Cloud platform or the standalone GWN.Manager software, enabling convenient network control and administration.
Grandstream GWN7630 Key Features:
- 2.33 Gbps wireless speed with dual Gigabit ports
- 4×4:4 MU-MIMO with dual-band support
- Auto-detects and adapts to PoE/PoE+ power
- Handles 200+ simultaneous Wi-Fi connections
- 175m coverage radius
- QoS optimization for latency-sensitive apps
- Enterprise-grade security with secure boot, digital signatures, and unique device certificates
- Manages 50 APs locally or unlimited via GWN.Cloud
Frequently Asked Questions
What is the default password for GWN7630?
The default password for the GWN7630 is "admin" for both the username and password. It is recommended to change this after the initial login to improve security.
How do you reset the Grandstream AP?
To reset the Grandstream AP, locate the reset button on the device, press and hold it for about 7 seconds, and then release. The device will reboot and return to its factory settings.
Only logged in customers who have purchased this product may leave a review.
WiFi Standards
- IEEE 802.11 a/b/g/n/ac (Wave-2)
Antennas
- Four dual-band internal antennas
- 2.4GHz, gain 4dBi
- 5 GHz, gain 5dBi
WiFi Data Rates
- IEEE 802.11ac: 6.5 Mbps to 1733Mbps
- IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- IEEE 802.11n: 6.5Mbps to 600Mbps
- IEEE 802.11b: 1, 2, 5.5, 11 Mbps
- IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- *Actual throughput may vary depending on many factors including environmental conditions, the distance between
devices, radio interference in the operating environment and mix of devices in the network
Frequency Bands
- 2.4GHz radio: 2412 – 2484 MHz
- 5GHz radio: 5180 – 5825 MHz
Channel Bandwidth
- 2.4G: 20 and 40 MHz
- 5G: 20,40 and 80 MHz
WiFi And System Security
- WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
MIMO
- 4×4:4 2.4G(MIMO)
- 4×4:4 5G(MU-MIMO)
Coverage Range
- Up to 175 meters
- *coverage range can vary based on the environment
Maximum TX Power
- 2.4G: 27 dBm
- 5G: 25 dBm
- *Maximum power varies by country, frequency band and MCS rate
Receiver Sensitivity
- 2.4G: 802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
- 5G: 802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:- 63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9
SSIDs
- 15 SSIDs per access point
Concurrent Clients
- 200+
Network Interfaces
- 2x autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports
- 1x Reset Pinhole, 1x Kensington lock
Mounting
- Indoor wall mount or ceiling mount, kits included
LEDs
- Three tri-color LEDs for device tracking and status indication
Network Protocols
- IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS
- 802.11e/WMM, VLAN, TOS
Network Management
- ≤ 50 APs: Light-weight Master in AP
- ≥ 50 APs: Cloud management (GWN.Cloud)
Power And Green Energy Efficiency
- Support 802.3 az ;
- POE 802.3af/ 802.3at;
- Max Consumption: 16.5W
Environmental
- Operation: 0°C to 40°C
- Storage: -10°C to 60°C
- Humidity: 10% to 90% Non-condensing
Physical
- Unit Dimension: 205.3 x 205.3 x 45.9mm; Unit Weight: 590g
- Unit + Mounting Kits Dimension : 205.3 x 205.3 x 50.9mm; Unit + Mounting Kits Weight : 710g
- Entire Package Dimension: 258 x 247 x 86mm; Entire Package Weight: 930g
