Grandstream GWN7665 Tri-Band Wi-Fi 6E Access Point
₦135,000.00
- 5.4Gbps aggregate wireless throughput, 3.5 Gigabit wireline ports
- Tri-Band 2×2:2 MU-MIMO with DL/UL OFDMA technology
- Up to 175-meter coverage range
- Support 384 concurrent Wi-Fi client devices
- Description
- SPECIFICATIONS
The Grandstream GWN7665 is a state-of-the-art tri-band Wi-Fi 6E access point, specifically engineered for high-capacity wireless networks. Boasting an innovative tri-band design, the GWN7665 offers concurrent 2.4 GHz, 5 GHz, and 6 GHz frequencies. It supports the newest Wi-Fi standard, the Wi-Fi 6E (802.11ax), delivering significantly improved network capacity, speed, and overall performance. With a maximum aggregated wireless rate of up to 5.4 Gbps and an extended coverage range, this product ensures the most reliable and consistent connection in even the most challenging environments.
In addition to its remarkable speed and range capabilities, the GWN7665 is equipped with advanced security features. These include a built-in controller for automated network provisioning, centralized management, and real-time monitoring. Moreover, it supports WPA3-Enterprise for enhanced security, QoS to prioritize data traffic for various applications, and MU-MIMO technology for increased network efficiency.
Constructed with industrial-grade materials, the GWN7665 exhibits exceptional durability and longevity. It also features an IP66-rated weatherproof casing making it suitable for both indoor and outdoor deployments. Furthermore, this access point offers easy installation with flexible mounting options to cater to different use-cases.
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Antennas | 7 individual internal antennas
2.4GHz x 2, gain 4.0dBi 5 GHz x 2, gain 5.0dBi 6 GHz x 2, gain 4.5dBi BT, gain 4.0dBi |
| Wi-Fi Data Rates | 2.4G:
IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps IEEE 802.11n: 6.5Mbps to 300Mbps IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 5G: IEEE 802.11ax: 7.3 Mbps to 2403 Mbps IEEE 802.11ac: 6.5 Mbps to 1734 Mbps IEEE 802.11n: 6.5Mbps to 300Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 6G: IEEE 802.11ax: 7.3 Mbps to 2403 Mbps IEEE 802.11ac: 6.5 Mbps to 1734 Mbps IEEE 802.11n: 6.5Mbps to 300Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network |
| Frequency Bands | 2.4GHz Radio: 2412 – 2484 MHz
5GHz Radio: 5180 – 5825 MHz 6GHz Radio: 5945 -7125MHz *Not all frequency bands can be used in all regions |
| Channel Bandwidth | 2.4G: 20 and 40 MHz
5G: 20, 40 80 and 160 MHz 6G: 20, 40 80 and 160MHz |
| Wi-Fi and System Security | WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/ control lockdown via digital signatures, unique security certificate and random default password per device |
| MU-MIMO | 2×2:2 2.4GHz
2×2:2 5GHz 2×2:2 6GHz |
| Coverage Range | Up to 175 meters
*coverage range can vary based on environment |
| Maximum TX Power | 2.4G: 24dBm
5G: 27dBm 6G: 26 dBm *Maximum power varies by country, frequency band and MCS rate |
| Receiver Sensitivity | 2.4G
802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7 802.11ax 20MHz: -60dBm @MCS11; 802.11ax 40MHz: -58dBm @MCS11 5G 802.11a: -90dBm @6Mbps, -72dBm @54Mbps; 802.11n 20MHz: -71dBm @MCS7; 802.11n 40MHz:-68dBm @MCS7; 802.11ac 20MHz: -65dBm@MCS8; 802.11ac: 40MHz:- 61dBm @MCS9; 802.11ac 80MHz: -57dBm @MCS9;802.11ac 160MHz: -55dBm @MCS9; 802.11ax 20MHz: -58dBm @MCS11; 802.11ax 40MHz: -56dBm @MCS11;802.11ax 80MHz: -54dBm @MCS11;802.11ax 160MHz: -51dBm @MCS11 6G 802.11a: -90dBm @6Mbps, -72dBm @54Mbps; 802.11n 20MHz: -71dBm @MCS7; 802.11n 40MHz:-68dBm @MCS7; 802.11ac 20MHz: -65dBm@MCS8; 802.11ac: 40MHz:- 61dBm @MCS9; 802.11ac 80MHz: -57dBm @MCS9;802.11ac 160MHz: -55dBm @MCS9; 802.11ax 20MHz: -58dBm @MCS11; 802.11ax 40MHz: -56dBm @MCS11;802.11ax 80MHz: -54dBm @MCS11;802.11ax 160MHz: -51dBm @MCS11 |
| SSIDs | 48 SSIDs total, 16 per radio (2.4GHz & 5GHz & 6GHz) |
| Concurrent Clients | 384 |
| Network Interfaces | 1x autosensing 10/100/1000 Base-T Ethernet Port
1x autosensing 10/100/2500 Base-T Ethernet Port |
| Auxiliary Ports | 1x Reset Pinhole, 1x Kensington lock |
| Mounting | Indoor wall mount or ceiling mount, kits included |
| LEDs | 3 tri-color LEDs for device tracking and status indication |
| Network Protocols | IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM |
| QoS | 802.11e/WMM, VLAN, TOS |
| Network Management | Embedded controller can manage up to 50 local GWN APs
GWN.Cloud offers a free cloud management platform for unlimited GWN APs GWN Manager offers premise-based software controller for up to 3,000 GWN APs |
| Power and Green Energy Efficiency | PoE 802.3at
Maximum Power Consumption: 22.55W |
| Environmental | Operation: 0°Cto 50°C
Storage: -10°C to 60°C Humidity: 10% to 95% Non-condensing |
| Physical | Unit Dimension: 205.3mmx205.3mmx45.9mm; Unit Weight: 765g
Entire Package Dimension: 258mmx247mmx86mm; Entire Package Weight: 1106g |
| Package Content | GWN7665 Wireless AP, Mounting Kits, Quick Start Guide |
| Compliance | FCC, CE, RCM, IC,UKCA |
