Grandstream GSC3570 HD Intercom & Facility Control Station

The Grandstream GSC3570 HD intercom & facility control station is a state-of-the-art communication solution designed for the modern, connected world. This device stands out as an exceptional choice for Nigerian businesses.

Key Features

1. HD Audio Quality: Experience crystal-clear communication with high-definition audio, ensuring every conversation is both pleasant and productive.
2. Multi-Platform Compatibility: Easily integrates with various security and facility management platforms, offering versatile use in diverse environments.
3. Advanced Intercom System: Facilitates efficient, two-way communication for both internal and external interactions, enhancing operational coordination.
4. Control Functions: Manage access and monitor facilities with ease, thanks to its intuitive control features, making it ideal for gated communities, corporate buildings, and other secured environments.
5. Touchscreen Interface: Navigate through functions effortlessly with its user-friendly touchscreen, making complex tasks simpler and more efficient.

Whether you’re managing a busy office complex, a residential estate, or a commercial facility, the GSC3570 ensures that you’re always connected and in control. Its adaptability to various systems means you won’t face compatibility issues, and its high-quality build promises durability.

Protocol/Standards

• SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV,NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LDAP, 802.1x, TLS, SRTP, IPv6

Network Interface

• Dual switched 10/100Mbps ports

Graphic Display

• 7’’ 1024×600 capacitive touch screen TFT LCD with Home key

WiFi

• Yes, dual-band 802.11 a/b/g/n/ac (2.4GHz & 5GHz)

Auxiliary Ports

• 4 x Alarm Input
• 1 x Alarm Output
• Micro SD card slot

Voice Codecs And Capabilities

• G.711μ/a, G.722 (wide-band), G.726-32, iLBC, Opus, G.729A/B, DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC, ANS

Video Decoders And Capabilities

• H.264 BP/MP/HP, video resolution up to 720p, frame rate up to 30 fps, bit rate up to 2Mbps

Telephony Features

• 4 SIP Accounts, Hold, Call Waiting, Call Log, Auto Answer, etc

Sample Applications

• Local apps: Contacts, Call History, Settings, Voicemail, Clock
• API/SDK available to allow integration with 3rd party door system products

Operating System

• Linux

HD Audio

• Yes, Dual speakers with support for wideband audio and media play in stereo, acoustic echo cancellation

QoS

• Layer 2 (802.1Q, 802.1p), 802.11e and Layer 3 (ToS, DiffServ, MPLS) QoS

Security

• Secure Boot & Data, Double images for high reliability, random administrator password, user and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES based secure configuration file, SRTP, TLS, 802.1x media access control

Multi-Language

• English and Chinese

Upgrade/Provisioning

• Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using AES encrypted XML configuration file, manual upload

Power & Green Energy Efficiency

• 2-pin DC input: 12VDC/1A
• Integrated PoE : IEEE 802.3af Class 3, power consumption <10W
• Micro USB input: 5VDC/2A

Temperature And Humidity

• Operation: -10°C to 50°C, Storage: -20°C to 60°C
• Humidity: 10% to 90% Non-condensing

Physical

• Unit Dimension: 224.5 x 149.5 x 36.5mm; Unit Weight: 516g

Package Contents

• GSC3570
• Quick installation guide
• Wall mount bracket
• Desktop stand (optional)

Compliance

• FCC, CE, RCM, IC
