Grandstream GWN7001 Multi-WAN Gigabit VPN Router
₦69,000.00
- Supports 6x Gigabit RJ45 ports
- Built-in VPN support
- Multiple WAN ports with load balancing and failover
- Advanced QoS
- Description
- SPECIFICATIONS
Description
This powerful router is designed to handle all your networking needs, from wired to wireless to virtual private network (VPN) connections. With its built-in firewalls and advanced security features, you can rest assured that your business data is protected from online threats.
The GWN7001 packs a punch with its high-performance routing and switching capabilities. It can manage up to 100 Grandstream GWN Series Wi-Fi access points, making it perfect for larger businesses or multiple locations. The router also supports traffic load balancing, failover, and bandwidth management, ensuring your network stays stable and reliable.
Setting up and managing your network has never been easier. The GWN7001 comes with a user-friendly web interface, and you can also use Grandstream’s free cloud-based and on-premises network management tools to monitor and control your network from anywhere.
Features of Grandstream GWN7001
- Supports 6x Gigabit RJ45 ports
- Built-in VPN support allows easy access to corporate networks for remote employees
- Multiple WAN ports with load balancing and failover to maximize connection reliability
- Rich firewall features including DDNS, port forwarding, DMZ, UPnP, Anti-Dos, traffic rules, NAT, and ALG
- Supports application/protocol monitoring and traffic statistics with Deep Packet Inspection (DPI)
- Advanced QoS to ensure real-time performance of low-latency applications
- Supports application, URL, DNS, and web content filtering to block access from unsecured contents
- Embedded controller can manage itself and up to 100 GWN APs; GWN.Cloud offers a free cloud management platform for unlimited routers and GWN APs
| CPU | Dual ARM Cortex A53 1GHz | |||
| Memory and NAT Sessions | 256MB RAM, 256MB Flash, 30K NAT sessions | |||
| Network Interfaces | 6x Gigabit Ethernet ports
*All ports support WAN/LAN configurable |
|||
| NAT Throughput | 2.2Gbps | |||
| IPsec VPN Throughput | 530Mbps | |||
| Auxiliary Ports | 1x USB 2.0 port, 1x Reset Pinhole | |||
| Mounting | Desktop and wall mounting | |||
| LEDs | 8 x single-color LEDs for device tracking and status indication | |||
| Connection Type | DHCP, Static IP, PPPoE, PPTP, L2TP | |||
| Network Protocols | IPv4, IPv6, IEEE802.1Q,IEEE 802.1p, IEEE802.1x, IEEE802.3, IEEE 802.3u, IEEE 802.3x,IEEE802.3ab | |||
| QoS |
VLAN, TOS Support multiple traffic classes, filter by port, IP address, DSCP, and policing App Qos VoIP Prioritization
|
|||
| Firewall | DDNS, Port Forwarding, DMZ, UPnP, Anti-DoS, traffic rules, NAT, ALG, TURN Service | |||
| Security |
Application/protocol monitoring and traffic statistics Content filtering: Supports Application/URL/DNS/Web Content Filtering Safe search
|
|||
| VPN |
SSL VPN Server / Client-to-Site IPsec VPN Client-to-Site / Site-to-Site PPTP VPN Server / Clien-to-Site L2TP Client-to-Site WireGuard (pending) IPSec Encryption: DES, 3DES, AES IPSec Authentication: MD5, SHA-1, SHA2-256 IPSec Key Exchange: Main/Aggressive Mode, Pre-shared Key, DH Groups 1/2/5/14 IPSec Protocols: ESP IPSec NAT Traversal SSL VPN Encryption: AES, DES SSL Authentication: MD5, SHA-1, SHA2-256, SHA2-384, SHA2-512 SSL VPN Certificate: RSA PPTP Encrpytion: MPPE 40-bit, 128-bit, IPSec PPTP/L2TP Authentication: MS-CHAPv1/2
|
|||
| Max Concurrent VPN Tunnels | Up to 50 Tunnels | |||
| Network Management | GWN7001 embedded controller can manage itself and up to 100 GWN APs | |||
| GWN.Cloud offers a free cloud management platform for unlimited GWN Routers and GWN APs. | ||||
| PoE Input | N/A | |||
| PoE Output | N/A | |||
| PoE Power Budget | N/A | |||
| Power & Green Energy Efficiency | Universal power adaptor included
Input: 100-240VAC 50-60Hz Output: 12V DC 1A (12W) |
|||
| Environmental | Operation: 0°C to 40°C
Storage: -30°C to 60°C Humidity: 10% to 90% Non-condensing |
|||
| Physical | Unit Dimension:
210mm(L)x130mm(W)x35mm(H); Unit Weight: 453g Entire Package Dimension: 246mm(L)x235mm(W)x54mm(H); Entire Package Weight: 672g |
|||
| Package Content | GWN7001 Router, Universal Power Supply, Network Cable, Quick Installation Guide | |||
| Compliance | FCC, CE, RCM, IC, UKCA | |||
