Grandstream GWN7003 Multi-WAN Gigabit VPN Router

0 out of 5

144,000.00

  • Supports 2x 2.5 Gigabit SFP ports and 9x Gigabit Ethernet ports
  • Built-in VPN support
  • Multiple WAN ports with load balancing and failover
  • Rich firewall features
WhatsApp Us for Details!
Brand

Grandstream

Availability: In stock SKU: GWN7003 Categories: ,

The Grandstream GWN7003 VPN Router is a high-performance networking solution designed to deliver enterprise-level features for businesses of all sizes. This device sports multiple Gigabit ports that facilitate high-speed, lag-free data transfers.

The GWN7003 supports up to three WAN ports which allow for optimal network failure protection through switch-over capabilities, ensuring seamless internet continuity and reliable connectivity. The router offers multi-core processing power which ensures that network traffic flows smoothly without any interruptions or lags. An impressive feature of the Grandstream GWN7003 is its advanced VPN capabilities.

With this router, users can set up secure VPN tunnels that encrypt data for secure transmission over the internet. This feature is particularly valuable for businesses that transmit sensitive information and require high-level security protocols. In addition, this router integrates comprehensive network security features including a built-in firewall and unique security certificate per device, providing an additional layer of protection against potential cyber threats. It also offers industry-leading endpoint security, providing an extra measure of safety to your network. The GWN7003 also includes support for comprehensive WiFi and VoIP protocols, making it an ideal choice for multi-device network environments.

CPUDual ARM Cortex A53 1GHz
Memory and NAT Sessions512MB RAM, 256MB Flash, 60K NAT sessions
Network Interfaces2x 2.5 Gigabit SFP ports and 9x Gigabit Ethernet ports

*All ports support WAN/LAN configurable

NAT Throughput2.2Gbps
IPsec VPN Throughput530Mbps
Auxiliary Ports1x USB 2.0 port, 1x Reset Pinhole
MountingDesktop, wall-Mount or rack-mount (rack-mount brackets included)
LEDs13x single-color LEDs for device tracking and status indication
Connection TypeDHCP, Static IP, PPPoE, PPTP, L2TP
Network ProtocolsIPv4, IPv6, IEEE802.1Q,IEEE 802.1p, IEEE802.1x, IEEE802.3, IEEE 802.3u, IEEE 802.3x,IEEE802.3ab
QoS

VLAN, TOS

Support multiple traffic classes, filter by port, IP address, DSCP, and policing

App Qos

VoIP Prioritization



FirewallDDNS, Port Forwarding, DMZ, UPnP, Anti-DoS, traffic rules, NAT, ALG, TURN Service
Security

Application/protocol monitoring and traffic statistics

Content filtering: Supports Application/URL/DNS/Web Content Filtering

Safe search



VPN

SSL VPN Server / Client-to-Site

IPsec VPN Client-to-Site / Site-to-Site

PPTP VPN Server / Clien-to-Site

L2TP Client-to-Site

WireGuard (pending)

IPSec Encryption: DES, 3DES, AES

IPSec Authentication: MD5, SHA-1, SHA2-256

IPSec Key Exchange: Main/Aggressive Mode, Pre-shared Key, DH Groups 1/2/5/14

IPSec Protocols: ESP

IPSec NAT Traversal

SSL VPN Encryption: AES, DES

SSL Authentication: MD5, SHA-1, SHA2-256, SHA2-384, SHA2-512

SSL VPN Certificate: RSA

PPTP Encrpytion: MPPE 40-bit, 128-bit, IPSec

PPTP/L2TP Authentication: MS-CHAPv1/2



Max Concurrent VPN TunnelsUp to 100 Tunnels
Network ManagementGWN7003 embedded controller can manage itself and up to 150 GWN APs
GWN.Cloud offers a free cloud management platform for unlimited GWN Routers and GWN APs.
PoE InputStandard: IEEE 802.3af/at
PoE Output2x PoE out ports

Passive 48V or IEEE802.3af

PoE Power Budget24V DC 1A: 12.8W

24V DC 1.5A: 24.8W

Power & Green Energy EfficiencyUniversal power adaptor included:

Input: 100-240VAC 50-60Hz

Output: 24V DC 1A (24W)

EnvironmentalOperation: 0°C to 40°C

Storage: -30°C to 60°C

Humidity: 10% to 90% Non-condensing

PhysicalUnit Dimension:

260mm(L)x149.35mm(W)*35mm(H);

Unit Weight: 1096g

Entire Package Dimension:

297mm(L)x255.5mm(W)x54mm(H);

Entire Package Weight: 1443g

Package ContentGWN7003 Router, Universal Power Supply, Network Cable, Quick Installation Guide, 8 x screws,1 x ground wire, 2 x mounting brackets
ComplianceFCC, CE, RCM, IC, UKCA
