Grandstream GWN7806P 48-Port Gigabit Layer 2+ Managed PoE Switch
₦863,000.00
- 48 Gigabit Ethernet ports and 6 Gigabit SFP+ ports
- Layer 2+ Managed Network Switch
- Smart power control to support dynamic PoE/PoE+ power allocation per port
- Supports deployment in IPv6 and IPv4 networks
- Description
- SPECIFICATIONS
Description
The Grandstream GWN7806P is a versatile Layer 2+ stackable managed network switch designed to help small and medium-sized businesses build robust, high-performance networks. With this switch, you can create a scalable and secure network infrastructure that is easy to manage.
The GWN7806P offers advanced VLAN support, allowing for flexible traffic segmentation, and advanced Quality of Service (QoS) features that ensure your most critical network traffic is prioritized. It also includes IGMP/MLD Snooping to optimize network performance and comprehensive security features to protect against potential threats.
This switch provides smart, dynamic PoE (Power over Ethernet) output, making it ideal for powering IP phones, IP cameras, Wi-Fi access points, and other PoE-enabled devices. The GWN7806P is user-friendly, with management options through its local web user interface and command-line interface (CLI). It also integrates seamlessly with Grandstream’s GWN-Cloud and GWN Manager, their cloud and on-premise network management platforms.
Features
- 48 Gigabit Ethernet ports and 6 Gigabit SFP+ ports
- Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models
- Supports deployment in IPv6 and IPv4 networks
- Reliability features include fault detection, device protection, dual boot, dual system file redundancy, link aggregation, storm control, and more
- ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
- Embedded controller to manage switch; GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform
- Built-in QoS allows for prioritization of network traffic
- Supports stacking for easy management of up to 16 switches in one interface while creating redundant backup between multiple devices
SPECIFICATIONS
| Network Protocol | IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af/at, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x | ||
| Gigabit Ports | 48 | ||
| SFP+ Ports | 6 | ||
| Note: Support DAC cable, and must be ≤ 5m | |||
| Maximum no. of Supported Modules | SM-10G: 6 MM-10G: 6 RJ45-10G: 3 | ||
| Note: RJ45-10G modules must be interval inserted | |||
| Console | 1 | ||
| # of PoE Ports | 48 | ||
| Integrated Power Supply | 470W | ||
| Maximum Output Power Per PoE Port | 30W | ||
| Max Total PoE Output Power | 400W | ||
| PoE Standards | IEEE 802.3af/at | ||
| Auxiliary Ports | 1x Reset Pinhole | ||
| Forwarding Mode | Store-and-forward | ||
| Total non-blocking throughput | 108Gbps | ||
| Switching Capability | 216Gbps | ||
| Forwarding Rate | 160.704Mpps | ||
| Packet Buffer | 16Mb | ||
| Switching | 32K static, dynamic and filtering MAC addresses 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN VLAN virtual interface GVRP (pending) 27 link aggregation Spanning tree, 64 instances for STP/RSTP/MSTP
| ||
| Routing | Static routing | ||
| Multicast | IGMP Snooping MLD Snooping MVR (pending)
| ||
| QoS/ACL | Port priority Priority mapping Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ Traffic shaping Rate limit 4K ACL for Ethernet, IPv4 and IPv6
| ||
| DHCP | DHCP server, DHCP relay, DHCP Option 82, 60, 160 and 43 | ||
| Maintenance | CPU and memory monitoring, SNMP, RMON, LLDP&LLDP-MED, backup and restore, syslog, diagnostics including Ping, Traceroute, port mirroring, UDLD(TBD) and copper test | ||
| Security | User hierarchical management and password protection, HTTPS, SSH, Telnet 802.1X authentication AAA authentication including RADIUS, TACACS+ Storm control Port isolation, port security, sticky MAC Filtering MAC address IP source guard, DoS attack prevention, ARP inspection DHCP Snooping Loop protection including BPDU protection, root protection(pending) and loopback protection(pending) Kensington Security Slot (Kensington Lock) support
| ||
| Mounting | Desktop, Rack-Mount(rack-mounting kits included) | ||
| LEDs | 1x tri-color LED for device tracking and status indication54x green-color LEDs for data transferring48x yellow-color LEDs for PoE powered (GWN7806P) | ||
| Fan | 3 | ||
| Environmental | Operation: 0°C to 45°C, humidity: 10% to 90% RH(Non-condensing) Storage: -10°C to 60°C, humidity:10% to 90% RH(Non-condensing) | ||
| Dimensions | 440mm(L)x301mm(W)x44mm(H) | ||
| Unit Weight | 5.1Kg | ||
| Package Content | Switch, 1x 1.2m(10A) AC Cable, 1x 25cm Ground Cable, 4x Rubber Footpads, 2x Rack-Mounting Kits, 8x Screws(PM 3*6), 1x Power Cord Anti-Trip, 1x Quick Installation Guide, 1x Console Cable(Optional) | ||
| Compliance | FCC, CE, RCM, IC, UKCA | ||
