Grandstream GWN7830 12Ports Layer 3 Aggregation Managed Switch
₦343,000.00
- 2 Gigabit Ethernet ports, 6 Gigabit SFP ports
- 4 10Gigabit SFP (SFP+) ports
- Managed Network Swicth
- Supports deployment in IPv6 and IPv4 networks
- Description
- SPECIFICATIONS
The Grandstream GWN7830 is a 12 Port enterprise-grade Layer 3 aggregation switch designed to create scalable, secure, and high-performance business networks. These switches are fully manageable, providing maximum network capacity and advanced features to meet the needs of growing enterprises. With support for sophisticated VLANs, the GWN7830 Series allows for flexible traffic segmentation, while advanced QoS ensures that critical network traffic is prioritized. Additionally, IGMP/MLD Snooping enhances network performance, and comprehensive security features protect against potential threats.
Managing the Grandstream GWN7830 is straightforward, with options including the local web user interface, CLI (Command Line Interface), and support from Grandstream’s cloud-based GWN-Cloud and on-premise GWN Manager platforms.
Features
- 2 Gigabit Ethernet ports, 6 Gigabit SFP ports, and 4 10Gigabit SFP (SFP+) ports
- Supports deployment in IPv6 and IPv4 networks
- ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
- Embedded controller to manage switch; GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise network management platform
- Built-in QoS allows for the prioritization of network traffic
| Network Protocol | IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x |
| Gigabit Ethernet Ports | 2 |
| Gigabit SFP Ports | 6 |
| Gigabit SFP+ Ports | 4 (Note: Support DAC Cable and must be ≤ 5m) |
| Maximum no. of Supported Modules | SM-1G: 6; MM-1G: 6; RJ45-1G: 3; SM-10G: 4; MM-10G: 4; RJ45-10G: 2 (Note: RJ45-1G, RJ45-10G modules must be interval inserted) |
| Console | 1 |
| Integrated Power Supply | 30W |
| External Redundant Power Supply( RPS) | / |
| Auxiliary Ports | 1x Reset Pinhole |
| Forwarding Mode | Store-and-forward |
| Total non-blocking throughput | 48Gbps |
| Switching Capability | 96Gbps |
| Forwarding Rate | 71.424Mpps |
| Packet Buffer | 12Mb |
| Network Latency | <4μs |
| Switching | 16K MAC addresses, including static, dynamic and filtering MAC address 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN VLAN virtual interface GVRP (pending) 6 link aggregation Spanning tree, 32 instances for STP/RSTP/MSTP |
| Routing | Static routing Dynamic routing, including RIP, RIPng, OSPF and OSPFv3 Policy routing(pending) |
| Multicast | IGMP Snooping with IGMPv2 and IGMPv3 MLD Snooping with MLDv1 and MLDv2 MVR (pending) |
| QoS/ACL | Port priority Priority mapping Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ Traffic shaping Rate limit 2K ACL for Ethernet, IPv4 and IPv6 |
| DHCP | DHCP server, DHCP relay, Option 82, 60, 160 and 43 |
| Maintenance | CPU and memory monitoring, fault detection and alarm for power supply and fan, SNMP, RMON, LLDP&LLDP-MED, backup and restore, syslog, diagnostics including Ping, Traceroute, port mirroring, UDLD(TBD) and copper test |
|
Security | User hierarchical management and password protection, HTTPS, SSH, Telnet 802.1X authentication AAA authentication including RADIUS, TACACS+ Storm control Port isolation, port security, sticky MAC Filtering MAC address IP source guard, DoS attack prevention, ARP inspection DHCP Snooping Loop protection including BPDU protection, root protection(pending) and loopback protection(pending) Kensington Security Slot (Kensington Lock) support |
| Mounting | Desktop, Wall-Mount or Rack-Mount (rack-mounting kits included) |
| System LEDs | 1x tri-colour LED for device tracking and status indication |
| Power Supply LEDs | / |
| Data Transferring LEDs | 12x green-colour LEDs |
| Fan | / |
| Environmental | Operation: 0°C to 45°C, humidity 10% to 90% RH(Non-condensing) Storage: -10°C to 60°C, humidity: 10% to 90% RH(Non-condensing) |
| Dimensions | 330mm (L)x175mm(W)x44mm(H) |
| Unit Weight | 1.91Kg |
|
Package Content | 1x Switch 1x 1.2m(10A) AC Cable 1x 25cm Ground Cable 4x Rubber Footpads 1x Power Cord Anti-Trip 2x Extended Rack-Mounting Kits 8x Screws (KM 3*6) 1x Quick Installation Guide 1x Console Cable (Optional) |
| Compliance | FCC, CE, RCM, IC, UKCA |
