Grandstream GXP1615 IP Phone

The Grandstream GXP1615 is an entry-level IP phone designed to optimize your communication experiences. This product boasts a sleek, compact design and a large 132×48 pixel LCD screen, which provides a clear display for easy navigation. The phone integrates dual 10/100 Mbps network ports with integrated Power over Ethernet (PoE), ensuring efficient power management.

The VoIP small business phone features full duplex speakerphone with advanced acoustic echo cancellation and excellent double-talk performance. This ensures high-quality, crystal-clear audio for both ends of the conversation, facilitating effective and efficient communication. Furthermore, it supports one SIP account and up to two call appearances while also containing a 3-way conferencing function.

The GXP1615 is equipped with EHS support for Plantronics headsets and a comprehensive set of telephony features. It incorporates large phonebook with up to 500 contacts and call history with up to 200 records, enhancing organizational efficiency. Lastly, the product comes with automated provisioning options including zero-configuration with Grandstream’s UCM series IP PBXs, encrypted XML files and TR-069, to make mass deployment easier.

Key Features of the Grandstream GXP1615:

• Supports 1 SIP account with up to 2 simultaneous call appearances.
• Enhances call security with TLS and SRTP encryption technology.
• Offers full-duplex speakerphone and HD audio for superior sound clarity.
• Enables 3-way audio conferencing to simplify group calls.
• Seamlessly integrates with Grandstream’s UCM series IP PBXs for Zero Config provisioning.
• Includes Electronic Hook Switch (EHS) support, compatible with Plantronics headsets.
• Provides automated provisioning through TR-069 and XML configuration files for easy setup.

Frequently Asked Questions

[sp_easyaccordion id=”8017″]

Protocols/Standards

• SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDPMED, LDAP, TR-069, 802.1x, TLS, SRTP, CDP/SNMP/RTCP-XR

Network Interfaces

• Dual switched auto-sensing 10/100 Mbps Ethernet ports, integrated PoE (GXP1615 only)

Graphic Display

• 132 x 48 LCD display

Feature Keys

• 2 line keys with dual-color LED and 1 SIP account, 3 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 13 dedicated function keys for PAGE/INTERCOM, PHONEBOOK, MESSAGE, HOME, HOLD, RECORD, MUTE, HEADSET, TRANSFER, CONFERENCE, SEND and REDIAL, SPEAKERPHONE, VOLUME

Voice Codecs

• Support for G.711µ/a, G.722 (wide-band), G.723,G.726-32, G.729 A/B, iLBC, in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC

Telephony Features

• Hold, transfer, forward (unconditional/no-answer/busy), 3-way conferencing, call park/pickup, downloadable phone book (XML, LDAP, up to 500 items), call waiting, call history (up to 200 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot desking, personalized music ringtones, server redundancy & fail-over

Headset Jack

• RJ9 headset jack (allowing EHS with Plantronics headsets)

Base Stand

• Yes, 2 angled positions available, wall mountable

Wall Mountable

• Yes

QoS

• Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS

Security

• User and administrator level access control, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access control

Multi-language

• English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, simplified and traditional Chinese, Korean, Japanese and more

Upgrade/Provisioning

• Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR069 or AES encrypted XML configuration file, FTP/FTPS

Power & Green Energy Efficiency

• Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA; PoE: IEEE802.3af Class 2, 3.84W-6.49W; IEEE802.3az (EEE) (GXP1615 Only)

Physical

• Dimension: 209mm (L) x 184.5mm (W) x 76.2mm (H) (with handset)
• Unit weight: 0.74kg
• Package weight: 1.1kg

Temperature and Humidity

• Operation: 0°C to 40°C, Storage: -10°C to 60°C , Humidity: 10％ to 90% Non-condensing

Package Content

• GXP1610/1615 phone, handset with cord, base stand, universal power supply, network cable, Quick Installation Guide, brochure, GPL License

Compliance

• • FCC: Part 15 (CFR 47) Class B CE : EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1 RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 60950.1

Datasheet

• Datasheet_GXP1615_english
