Cambium C050910D301A | ePMP 4 x 4 MU-MIMO 17dbi 90deg Sector Antenna

Cambium Networks’ ePMP 3000 Sector Antenna consistent gain from 4.9 to 6.0 GHz allows the operator to select a channel anywhere in the band and achieve the expected performance. Excellent null fill capabilities of the antenna allow for broad
geographical coverage within a sector even near the base of the tower and the edges of the sector. Small, compact design, integrated ePMP radio mount and GPS antenna integration. The sector antenna is integrated into Cambium Networks LINKPlanner. The 3D model shows coverage at all elevations and across the azimuth

Product Features
17dBi Gain
4.9 to 5.97GHz Spectrum
30dBi Front to Back Ratio
IP 65 Ruggedization

Product Specifications
Model Number C050910D301A
Frequency Range 4.9 GHz to 5.97 GHz
Gain 17 dBi
3 dB Beamwidth Azimuth 70 degrees
3 dB Beamwidth Elevation 6 degrees
Electrical Downtilt -2 degrees
Polarization 2X Horizontal, 2X Vertical
Model Number C050910D301A
Port-to-Port Isolation > 20 dB
Front-to-Back Ratio 30 dB
Maximum Input Power 5 W
Input Impedance 50 ohms
Mounting Connectors 4 x RP SMA
Mounting Hardware Included for mounting to mast diameters 2″ to 4″ (5 cm to 10 cm) -10 to +5 degree tilt
Hardware included to connect ePMP access point to back of antenna body
Physical Dimensions Antenna Body: 23.4″ (H) x 9.6″ (W) x 3.25″ (D) (594 mm x 157 mm x 110 mm)
Weight Antenna Body: 8.0 lbs, 3.7 kg w/ ePMP 3000 Access Point and Mounting Brackets: 13.8 lbs. 6.3 kg
Environmental IP65
Radome Material UV Protected ABS
Operating Temp -400C to 600C (-400F to 1400F)
