Grandstream GWN7700P 4 Port Unmanaged PoE+ Switch
₦59,500.00
- 5 Gigabit RJ45 ports, 4 port PoE+ outputr
- Auto MDI/MDIX crossover for all ports
- 802.3 af/at compliant
- Up to 30W on each port
- Description
- SPECIFICATIONS
Description
The Grandstream GWN7700P is a straightforward unmanaged network switch designed to deliver high-speed Gigabit connectivity for home offices and small-to-medium-sized businesses. These switches offer a hassle-free setup with no need for configuration or complex installation. It features a versatile design that can be placed on a desk or mounted on a wall, and their auto MDI/MDIX function eliminates the need for crossover cables, making them even easier to use.
Each port in the GWN7700P series automatically negotiates the best connection speed, ensuring compatibility and optimal performance with any 10/100/1000Mbps network device. For added convenience, the PoE (Power-over-Ethernet) models in this series provide smart, dynamic PoE output that complies with IEEE 802.3af/at standards. This allows the switches to power IP phones, IP cameras, Wi-Fi access points, and other PoE-enabled devices directly through the network cables.
Features of the Grandstream GWN7700P
- 5 Gigabit RJ45 ports, 4 port PoE+ output
- Green technology reduces power consumption
- LED Indicators; Per port: Link/Activity/Speed Per device: Power
- Auto MDI/MDIX crossover for all ports
- 802.3 af/at compliant Up to 30W on each port,
- Broadcast/Multicast/Unicast Storm Control (fixed to 100Mbps) to monitor traffic levels
- QoS – Supports Default Strict Priority when present
SPECIFICATIONS
| Gigabit Ports | 5 | |
| PoE Ports | 4 | |
| Metal | ||
| Mounting | Desktop/ Wall-Mount | |
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at | |
| Port Feature | 5× 10/100/1000Mbps RJ45 Ports AUTO Negotiation AUTO MDI/MDIX | |
| Network Media | 1000Base-T/100Base-TX/10Base-T, Half/Full-Duplex | |
| PoE Configuration | 1~4 Ports 802.3 af/at compliant Up to 30 W on Each Port, Total 60W Power Budget; Overload to cut off the lowest-priority port. Priority: Port 4 to Port 1
| |
| LED Indicators | Per port: Link/Activity Green Per device: Power Green | |
| Mac Address Table | 2K | |
| Switching Capacity | 10Gbps | |
| Jumbo Frame | 9KB | |
| Advanced Features | Mac Address Auto-Learning And Auto-Aging IEEE 802.3x Flow Control 802.1p/DSCP QoS IGMP: IGMP Fast-Leave IGMP Snoop Route Port Autolearn Query Refresh Member Port
| |
| Power Adapter | External 48-53.5VDC/1.22A | |
| Max Power Consumption by Base System | 2W (excluding PoE output power) | |
| Environmental | Operating Temperature: 0 to 40 °C (32 to 104 °F) Storage Temperature: -40 to 60 °C (-4 to 140 °F) Operating Humidity: 10% to 90% Non-condensing Storage Humidity: 5% to 90% Non-condensing | |
| Dimensions (L x W x H) | Unit: 145 x 80 x 27mm Package: 230 x 190 x 51mm | |
| Weight | Unit Weight: 0.26KG Entire Package: 0.75KG | |
| Package | 1x Switch, 1x Power Adapter,1x QIG | |
| Compliance | FCC, CE, RCM, IC, UKCA | |
