Spool of RG11/U Coaxial Cable (1000′)

What’s
special about this dual shielded RG11?

Shielded
RG11 coaxial cable designed for transmitting a
video/Satellite signal over longer lengths of cable, making it perfect
for security devices in a hospital, schools or large warehouses
HDTV capable due
to the RG11’s ability to project a stronger more dependable signal
Available
with either dual shields to protect from Crosstalk or interference
Pure
Copper Inner Conductor

Creating
a quality digital installation is the goal of every installer, so this
is why many of them rely on superior RG11 coaxial cable. Its
stronger signal allows for longer runs of cable, and its exceptional
speed make it the perfect choice for many digital video applications,
including HDTV

Specifications:
Meets MIL-C-17 standard
Description:
RG-11 coaxial cable is used in the networks of
satellite and cable television
Materials:
Conductor: Copper
Dielectric: low density cellular polyethylene
Shield: aluminium foil and copper wire braid
Jacket material: PVC (polyvinylchloride)
Technical
characteristics:
Wave impedance: 75 Ohm
Conductor diameter: 1.62 mm (0.06) (14 AWG)
Dielectric diameter: 7.11 mm (0.28)
Outer jacket thickness: 1.1 mm (0.04)
Outer cable diameter: 10.16 mm (0.4)
Shield: 0.18 mm (0.007), cover 60% minimum, aluminium foil
Test frequency: up to 3 GHz
Voltage rating: 5000 V
Temperature range: -20C +80C (-4F +176F)
Weight per 1000 ft (304.8 m): 30.2 kg (66.5 lbs)
Minimum bend radius: (cabling) 114.3 mm (4.5)
Pulling tension: 117.9 kg (259.9 lbs)
Capacitive resistance: 53.1 pF/m
Signaling rate: 83%
