Cisco SG110-16HP-NA 16 Ports Gigabit POE unmanaged Switch

About Cisco SG110-16HP

Affordable, Easy-to-Use Switches for Small Business Networks, with
Zero Configuration Required

Give your office network a boost of speed and performance at a low
price that takes almost no time to set up. Easily build a highly
reliable network to connect your computers, printers, copiers and other
office equipment. If your business is like most small companies, you do
not have an IT staff to set up your network for you. Now you can have a
high-performance, business-class office network that just works, right
out of the box, with the Cisco 110 Series Unmanaged Switches. Users,
workgroups, labs, departments or growing offices can now deliver large
amounts of multimedia, image and video information across the network
in almost no time.

Cisco 110 Series Unmanaged Switches deliver basic network connectivity
and reliability for small businesses that is easy on the budget and
without all the complexity. These switches provide all of the features,
expandability and investment protection you expect from Cisco, with no
installation software and nothing to configure. Just plug it in,
connect your computers and other business equipment and get to work.

Cisco 110 Series Unmanaged Switches part of the Cisco Small Business
networking solutions, are a line of unmanaged switches that provide
wire-speed Fast Ethernet and Gigabit Ethernet connectivity to connect
your small business office. Available in desktop and rack-mount models,
these switches are designed to suit any office space with basic network
needs and to optimize power efficiency. They use less power and provide
the robust, reliable connectivity your business demands, as well as
support for advanced features such as quality of service (QoS), loop
detection and cable diagnostics, all in a switch that you can set up
yourself in minutes. A business-class, affordable network solution,
Cisco 110 Series switches bring the proven reliability and investment
protection of Cisco networking solutions to your small business.

Cisco SG110-16HP Specifications

Standards

IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u
100BASE-TX Fast
Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit
Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient
Ethernet,
802.3af, Power over Ethernet

Cabling type

Category 5e or better

LED indicators

System/PWR, link/activity, 100M,PoE, mMax PoE,
cable
diagnostics, loop detection, gigabit, mini-GBIC

Power supply

Internal, universal: 10-240VAC, 50-60 Hz

Lock slot

Slot for Kensington lock

Ports

16x RJ-45 connectors for
10BASE-T/100BASE-TX/1000BASE-T
ports

Power over Ethernet (PoE)

Power Dedicated to PoE: 64W
Number of PoE Ports: 8

Fanless

Yes

Switching capacity

32 Gbps

Forwarding capacity

Forwarding rate in million packets per second
(mpps) (based
on 64-byte packets): 23.8 mpps

Head-of-line (HOL) blocking

HOL blocking prevention

Jumbo frame

9216 bytes

Quality of service (QoS)

802.1p priority based, 4 hardware queues, priority
queuing
and weighted round-robin (WRR)

Loop detection

Helps discover loops in the network to avoid
broadcast
storms

Cable diagnostics

Quickly identify and troubleshoot network cable
faults
and/or shorts

Mounting options

Desktop or Rack mount

Physical security lock

Kensington lock slot

Minimum Requirements

Devices supporting 802.3 Ethernet, 802.u Faster
Ethernet, or
802.3ab Gigabit Ethernet
Cat5 or better Ethernet cable
Network interface card for each computer

Compliance/certifications

UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part
15 (CFR 47)
Class A, FCC Class B

Operating temperature

32 to 104deg. F (0 to 40deg. C)

Storage temperature

-4 to 158deg. F (-20 to 70deg. C)

Operating humidity

10% to 90%, relative, noncondensing

Storage humidity

5% to 90%, relative, noncondensing

System memory

128-MB RAM
128-MB Flash

Dimensions (WxDxH)

11 x 1.75 x 6.7 (279.40 x 44.45 x 170.18mm)

Weight

4.15 lbs (1.88kg)
