DES-12G Slave RS485 Fingerint/Password/Card Reader for Access Control

DES-12G Fingerprint Slave reader

DES-12G is designed for middle and small-sized company, it is a standalone fingerprint door access control terminal designed for easy operation and installation

fingerprint capacity:500 response time:0.8s
record capacity:100,000
verify mode:fingerprint, password, ID card
working voltage/current:DC9V~12V/1A
function:standard WG26/34 output /relay output/ BELL

(Model can be used as a slave fingerprint & card reader)

Product description

SPECIFICATIONS:

Item: DES-12G

Operating Voltage: DC 12V10%

Standby Current: <100mA Relay Contact Load Capacity: 3A Operating Temperature: -10C-50C Operating Humidity: 20%-60% User Capacity: 5000 Access To Record Capacity: 130,000 Access Period: Group 8 Fingerprint Entry Speed: <1s FAR: <0.0001% FRR: <0.01% Wiegand Signal: Input/Output WG26/WG34 Access Control Interface For: Lock, Door Sensor, Exit Button, Alarm, Door Bell, Anti-passback Optional Function: Mifare Card, ID Card, GPRS/WIFI Communication: TCP/IP, USB Cable
